6000 PSI Instrument Ball Valve 1/4 1/2 Inch SS316 PEEK Seat NPT BSPP BSPT Metric Thread OEM High Pressure Valve
$58
/pieces
Price varies depending on material, logo, quantity and customization requirements.
Quality You Can Trust
Flexible & Scalable Solutions
Customizable Product Options
Comprehensive Specifications
Your Reliable Business Partner
Category:
Shutoff Valves
Introduction
| Connection Size | 1/2 in, 1/4 in, 3/4 in, 3/8 in, 1 in | Operating Pressure | 6000PSI |
| Operating Temp. Range | -22-140F | media | Oil and Gas |
| Sealing Material | PTFE | Connection Type | Flanged, NPT, Thread, True Union |
| power | Manual | Ball Material | SS |
| Port Size | 1/4 in, 1 in, 3/4 in, 1/2 in | Flow Rate | 300 m³/h(10594.40ft3/h) |
| For Maximum Pipe Size | 15 mm, 20 mm, 25 mm | application | Oil and Gas |
| temperature of media | Normal Temperature | structure | Ball |
| customized support | OEM, ODM | Max Working Pressure | 6000 PSI (414 Bar / 41.4 MPa) |
| Testing Standard | 100% Nitrogen Leak Tested @ 1000 PSI | Seat Material Options | PEEK / PCTFE / PTFE (Optional) |
| Body Material | ASTM A479 SS316 / SS316L / Duplex / Hastelloy /monel /inconel | Applicable Media | CNG, LNG, Hydrogen, Nitrogen, Oil, Gas |
| Mounting Pad | ISO 5211 Standard for Actuator | Stem Design | Safety Blow-out Proof Stem |
| Product name | CNG High Pressure 6000psi Ball Valve | Thread Standards | NPT, BSPP, BSPT (G & R Threads |
| Temperature Range | -28°C to 232°C (-20°F to 450°F) |
We are a professional manufacturer and supplier, dedicated to maintaining consistent quality and establishing long-term partnerships with clients worldwide.
Our mission is to provide high-quality products and reliable service. We are committed to offering the following advantages:
- Stable production system ensuring consistent quality, dependable supply, and standardized manufacturing management;
- Strict quality control covering material selection, processing, surface finishing, and final packaging;
- Variety of products and specifications to meet diverse project requirements and application scenarios;
- OEM & customization support based on drawings, samples, or specific technical requirements;
- Flexible packaging solutions to ensure safe handling and transportation of products;
- Continuous improvement in products and services to better support customers in different markets.
If you are interested in our products, please feel free to contact us. We look forward to establishing long-term and mutually beneficial cooperation with you.
