Custom Solenoid Driven Two Way Hydraulic Threaded Insert Valve Used for Low Flow Hydraulic Circuit Load Maintenance Shutoff
$13-13.50
/pieces
Price varies depending on material, logo, quantity and customization requirements.
Quality You Can Trust
Flexible & Scalable Solutions
Customizable Product Options
Comprehensive Specifications
Your Reliable Business Partner
Category:
Shutoff Valves
Introduction
| Valve type | Solenoid Valve | Number Of Ways | Two-way |
| Maximum pressure | 207bar(3002.28psi) | Maximum Flow Rate | 30.2L/min(7.98gpm) |
| Port Connection Size | 1/4 in | Pressure Connection | 3/4 in |
| Flow Range (gpm) | 8gpm | Showroom Location | None |
| Dimension(L*W*H) | 93*20*16.5(mm) | Weight | 0.09 |
| Power(W) | - | Pressure | - |
| Structure | - | Maximum operating pressure | 207 bar(3000psi) |
| Maximum flow | 30.2L/min(8gpm) | Coil Duty Rating | Continuous from 85to 115of nominal voltage |
| Maximum internal leakage | 0.15ml/min(3drops/min)@207bar(3000psi) | Installation torque | 20ft-lbs(27.1Nm),Hex22.4 |
| Oil Temperature Range | -40°Cto120°C( seals matching required) | Fluids | Mineral-based or synthetics with lubricating properties |
| Viscosities | 7.4 to 420 cSt(50-2000ssu) | Filtration | 20/18/15 ISO4406(maximum filtration admitted) |
| Cavity | IVC08-2 |
